This space-saving 24-pin connector insert offers ≤3mΩ contact resistance and operates from -40℃ to 125℃. With crimp terminals (0.14-2.5mm²) and 7.5Nm torque, it excels in hot runners and construction machinery. OEM solutions are available.
24 pins solution, with male inserts HDD-024-MC
| Termination Method to Wire & Cable | Crimp Terminal |
| Order No. | 09160243101 |
| Body Material | Polycarbonate |
| Rated Voltages | 250V |
| Rated Current | 10A |
| Pins | 24 Pins |
| Rated impulse voltage | 4kV |
| Rated voltage acc. to UL/CSA | 600V |
| Pollution degree | 3 |
| Limiting temperatures | -40℃…+125℃ |
| Insulation resistance | ≥1010Ω |
| Flammability acc. to UL 94 | V0 |
| Mechanical working life (mating cycles) | ≥500 |
| Certificate | ISO9001/CE |
| Applications | Photovoltaic Industry, Energy Distribution, hot runners, Wind power generation, Construction Machinery, Renewable Energy, etc. |
| OEM | Provided |
| Material | Copper Alloy |
| Surface | Hard-gold Plated
Hard-silver Plated |
| Contact Resistance | ≤3mΩ |
| Wire Gauge | 0.14-2.5mm^2 |
| AWG | 26-14 |
| Tightening Torque | 7.5Nm |
