Hot Runner Connector in hot runner system

This is Hot runner systems with heavy duty connector

Injection molding relies on precise temperature control to produce high-quality plastic parts, and hot runner systems are at the heart of this process. Hot runner connector (also known as heavy-duty connector) plays a key role in ensuring that these systems operate reliably under extreme conditions. This article will explain their applications and advantages.

What is a Hot Runner Connector?

A hot runner connector is a specialized heavy duty electrical component designed to deliver power, signals, and data within hot runner systems. These connectors link heaters, thermocouples, and control units, maintaining consistent heat distribution across the mold.

heavy duty in hot runner system

Applications in Hot Runner Systems

Power supply for heaters

Temperature Control

Sensor Integration

Data Communication

Key Advantages of Heavy Duty Connectors in Hot-Runner Systems

1. Extreme Temperature Resistance

Operate continuously at 200°C–250°C near heaters.

UL 94 V-0 rated housings prevent melting or deformation.

2. Sealed Against Contaminants

IP675/IP68 protection resists dust, humidity, water, or other fluids such as cleaning and cooling agents, oil, etc.

Silicone gaskets maintain sealing at high temperatures.

3. Stable Electrical Performance

Gold-plated contacts minimize resistance drift.

EMI shielding (360°coverage) protects low-voltage signals.

4. Mechanical Durability

1,000+ mating cycles with stainless steel locking levers.

Vibration-proof design for press-side mounting.

Why Choose UMER Hot Runner Connectors?

UMER’s connectors are engineered for injection molding challenges:

Heat-Resistant Materials: high-strength aluminum alloy hoods and housings, and gold or silver-plated contacts.

Custom Configurations: Mix power (50A), signal (24V), and data contacts.

Global Compliance: UL, CE, and ISO certified.

Quick-Connect Designs: Reduce mold setup time by 30%.

One-stop professional service: We offer 24-hour one-on-one service to provide you with selection assistance and installation guidance.

Explore UMER’s Solutions:

HEE Series: Compact connectors for tight spaces between nozzles.

HDD Series: High-current models for multi-zone heating.

Contact UMER Today for samples or download our catalog!
